Netra[tm] t1 100/105 Servers

T105
Sun T105

Racking |Processors | Main Memory | Standard Interfaces | Internal Mass Storage
Environment | Regulations | Dimensions and Weight

Racking
top

X6920A - Rack Mount Kit for T105
Fits into 19-, 23-, 24-in., 600 mm racks (includes mounting kit for 19-in. racks)


Processors
top

Number: One

Architecture: 360- or 440- MHz UltraSPARC-IIi, single processor, Superscalar SPARC Version 9

Cache Memory:16-KB data and 16-KB instruction on chip

Secondary: 1-MB external with 360-MHz CPU, 2-MB external with 440-MHz CPU

501-5578 - Netra T105 motherboard

Main Memory
top

Capacities: 64-, 256-, and 512-MB memory cards

X6983A - 64 MB Mezzanine Memory
X6985A - 256MB Netra Mezzanine Stackable Memory Card
X6986A - 512MB Netra Mezzanine Memory Card

Total of two Sun Mezzanine memory cards supported 1.0 GB maximum (Total of four 256 MB memory cards can be installed in select units only)

Standard Interfaces
top

Ethernet: Two ethernet/fast ethernet (10BASE-T/100BASE-T) shielded twisted-pair port ( RJ-45)
X1034A - Quad FastEthernet PCI (QFE/P)
X1141A - Gigabit Ethernet PCI (GBE/P) 2.0

PCI: Single 2/3-length, 32-bit, 33-MHz PCI 2.1 compliant slot

SCSI: One 40-MB/sec, 68-pin, UltraSCSI (SCSI-3) port
SG-XPCI2SCSI-LM320 - PCI/PCI-X Dual Ultra320 SCSI Adapter
X6541A - Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)

Serial: Two RS-232C/RS-423 serial ports ( RJ-45)

Internal Mass Storage
top

Disks: Up to two 3.5- x 1-in. disks (9 GB or 18 GB); front accessible; support for hot plug
X5229A - 9.1GB Ultra SCSI 7200 RPM
X5234A - 9.1GB Ultra SCSI 10000 RPM
X5237A - 18.2GB Ultra SCSI 10000 RPM
X5247A - 18.2GB - 10000 RPM

CD-ROM: Optional 644-MB Slimline CD, 24X speed
370-4278 - 24X Slimline CD-ROM Drive
Enviornment
top

300-1447 - Power Supply for T105
AC input (model 105): 100 - 240 VAC, 47 - 63 Hz, 2 A (max)

DC input (model 100): -40 to -75 VDC, dual input, 4 A (max)

Input power: 108 W

Heat Output: 368 BTU/hr

Temperature*: Operating: 0° C to 40° C (32° F to 104° F)
Operating (short term): -5° C to 55° C (23° F to 131° F)
Nonoperating: -40° C to 70° C (-40° F to 158° F)

Humidity: Operating: 5% to 85% relative humidity, noncondensing
Nonoperating: 10% to 95% relative humidity, noncondensing

Altitude: Operating: -300 m to 3000 m (-1000 ft. to 10,000 ft.)
Nonoperating: -300 m to 12,000 m (-1000 ft. to 40,000 ft.)

ETSI: ETS 300-19-2-3, Table 3.1, Climatic

Acoustic noise: Operating: <60dBA
Idling: <60dBA

Seismic: GR-63-Core requirements for earthquake risk zone 4 ETSI ETS 300-19-2-3, A1 operating requirements

Number of cords: 1

Plug Type-U.S.: NEMA 5-15P

* Short term is defined as no more than 96 hours duration at extremes and at elevations less than 1800m

Regulations :(meets or exceeds the following requirements)
top

Safety: UL 1950/CSA C22.2 No. 950, EN 60950 (73/23/EEC), IEC 950

Emissions: CFR Title 47 FCC Part 15, EN 55022 (89/336/EEC)

Immunity: EN 50082-1 (89/336/EEC)

Telco environment: Telcordia: GR-63-CORE, GR-1089-CORE, TR-NWT-000295, SR 3580 NEBS Level 3

Certification: Safety: cULus Mark, TUV GS Mark, CE Mark

EMC: CE Mark (93/68/EEC), FCC authorized Class A

Dimensions and Weights
top

Height : 44.0 mm (1.73 in.)

Width: 437.2 mm (17.21 in.)

Depth: 487.4 mm (19.19 in.)

Weight: 9 kg (20 lbs.)

Shipping Weight (product and packing): 11.5 kg (25 lbs.)

Netra T1 AC200 - 1 : Netra t1 105 - 2 : Netra t1 105 - 3 : Netra t1 105 - 4 : Netra t1 105 -Base-440 : Netra t1 105 - 1 : Netra t1 105 -Base-360 :
